Cometa VBR 01 BR Feed-of the arm machine (U-Type), single needle, bottom feed, needle feed, alternating feet, lockstitch.

Cometa VBR 01 BR Feed-of­ the arm machine (U-Type), single needle, bottom feed, needle feed, alternating feet, lockstitch.
Designed according to a very new concept, it allows stitching of tubular particulars and flters, shoes and leather goods in general, thanks to the reduced dimensions of arm.

Small vertical hook

Possible variants of arm

Arm length 260 mm – VBR MOD. 01 ROVESCIO-260

Arm length 400 mm – VBR MOD. 01 ROVESCIO-400

Arm diameter 50 mm

Maximum sewing speed 1600 rpm

The machine head DA-267-373 (0267 990257) is in use.

Complete with motor, support, standard table and pneumatic foot lift.

OPTIONAL-Additional:

• Automatic bartaking
• Micrometer guide
• Electronic handwheel
• LED light
