Duerkopp Adler 513 | CNC-controlled automatic lockstitch bartacker

Ideal solution for bartacking operations

The step motor-controlled clamp lift ensures
shorter cycletimes and thus increased
efficiency. Furthermore, the easy operation
and the simple
adaptation of the bartack patterns
to individual requirements allow flexible and fast
sewing in light to medium
weight fabric.

Your benefits at a glance

·
LCD
Control panel. Convenient for editing, saving and recalling
bartack shapes

·
Symbols as well as
the simple design make the
control panel very user-friendly. The standard bartacks can be rapidly
adapted to the different applications
and stored, if required. Furthermore,
modified standard bartack patterns and sequence programs
can be assigned
to the favourite
buttons so that they are
quickly retrievable.

·
Short thread trimmer. The short thread
trimmer enables a remaining thread length of only
~ 3 mm. This ensures that no
separate trimming operation is required.

·
Conversion kit “Heavy” (optional).
Superior quality, excellent performance

·
The optionally available conversion kit “Heavy” allows bartacking operations also in medium to
heavy-weight materials.

·
No pollution. Clean clothes and clean environment

·
The fully sealed internal
lubrication mechanism prevents pollution of the sewing
material. This also reduces the
noise level during operation. The targeted distribution of the lubricants
extends the service life and
helps to save resources.

·
“Pattern Design Software” (optional).
The optionla “Pattern Design Software” (parts-no.
0513 590024) enables easy and fast creation
of individual tack patterns on
the PC. The tack patterns can be
easily transferred to the 513 control
unit via an USB flash drive.

·
Contraction clamp (optional). Optional contraction clamp for buttonhole bartacks (part no. 513 590014) The automatic bartacker can optionally
be equipped with a contraction clamp for bartacking
buttonholes. When the clamp is
lowered, the arms of clamp
presses the buttonhole together. The buttonhole is thus
perfectly closed after bartacking.

·
Versatile applications for bartacking oprations. The automatic bartacker
513 is equipped as standard with
the clamping foot set no.
2, which is ideally suited for cross tacking
in standard material. The clamping foot set no.
18 (part no. 0512 220184) for double D-tacking
in piping pockets is optionally
available

·
Stepper motor controlled clamp lifting. Short cycle time for
higher efficiency due to stepper
motor-controlled clamp release.

Examples of use

·
Pocket openings. Clamp foot set no. 18 (part no.
0512 220184) for double D-tack on piped
pockets is available as an
option.

·
Pocket flaps. The optional
“Pattern Design Software” (part no. 0513 590024) allows easy and
quick creation of individual tack
patterns on the PC. The tack patterns can easily
be transferred to the control
unit of the
513 via USB stick.

·
Belt loops. The clamping
foot set no. 20 (option, part no. 0512 220204) is predestined for tacking belt
loops.The clamping foot set
no. 2 (part no. 0512 220024) is suitable for standard
crossbars and can be used
for bar sizes
up to max.
20.0 mm x 4.5 mm – for a wide range
of applications.

·
Buttonhole tack. Buttonhole bartack Optional
contraction clamp for buttonhole bartack (part-no. 513 590014):
The automatic bartacker can be optionally
equipped with a contraction clamp for bartacking buttonholes. When lowering the clamp,
the clamp pairs press the
buttonhole beads together. The buttonhole is thus perfectly
closed after bartacking.



Technical specifications

Feature	Technical Details
Stitch Length	0.1 – 10 mm
Stitches/min.	3,200 *
Sewing Material	LM or MS
Sewing Field Size	40 x 30 mm
Needle Type	Single Needle
Stitch Type	Lockstitch (301)
Hook Type	Horizontal, Small (S, Ø 22mm), CB Hook
Feed Mechanism	Clamp– or Rail Top Feed
Thread Trimmer	Short, 3mm
Counters	Piece counter/ Bobbin capacity counter
Thread Wiper	Yes
Clearance When Lifting	17 mm
Standard Seam Patterns	100
Memory Capacity (Stitches)	16,000
Storage Locations for Modified Seams	100
Number of Sequences	25
Seam Patterns per Sequence	30
CNC Contour Control with Program Control	Yes





Feature	Technical Details
Needle system	134
Needle size	80-110
Synthetic Thread Size	50/3 – 150/3
Cylinder arm machine clearance	C=180 / D=85
Nominal voltage	1x230V, 50/60 Hz
Rated power	500
Weight, sewing head	58 kg
Packaging size (L/W/H)	870 / 430 / 890 (mm)
